Low Flow - Flow Rate Indicator
Low Flow - Flow Rate Indicator
Design
The Flow-mon Low Flow Unit is a robust flow indicator specifically designed to manage low flow rates of liquids and gases.
Its basic design provides a simple and robust accurate measurement well suited to harsh industrial process applications.
It is easy to install and can be mounted in any orientation offering threaded or flanged connections with very low pressure loss.
Applications
- Water
- Soluble Oils (Glycols)
- Synthetic Based Fluids
- Corrosive Fluids
- Solvents
- De-ionised Water
- Petroleum Based Fluids
- Coolants
- Paints
- Air & Gases
- For flow ranges between 50cc to 5L/min
- Individually calibrated to any unit of measure
- Accuracy +/- 3% across full scale
- Single or dual scale
- Low pressure drop
- Viscosities up to 600cSt
- 1% rate of repeatability at switch set point
- Installed in any position
- Weatherproof enclosure box
- Available in a wide range of materials
Flow-Mon Accreditations
