Plastic Sight Flow Indicator
Plastic Sight Flow Indicator
The Plastic Sight Flow Indicator is a robust, low-cost industrial class flow indicator that is simple to install. It can be mounted in any position from vertical to horizontal without any special connectors or plumbing.
Constructed of high impact polycarbonate plastic, this product offers excellent structural integrity and compatibility with a wide range of industrial chemicals. The transparent polycarbonate plastic body allows visual inspection of the fluid condition as well as viewing the centrifugal movement of the internal impeller.
Applications
- Water
- Oils
- Coolants
- Chemicals
- Corrosives
- Air & Gases
- 1/4 inch to 1 inch BSP/NPT connection
- Easy to install in any position
- No special piping or connections required
- Robust with good shock and vibration resistance
- Resistant to a wide range of chemicals
- Temperature – 80°C (maximum working temperature)
- Pressure – 40 bar (maximum working pressure)
Flow-Mon Accreditations
