Rising Ball Sight Flow Indicator
Rising Ball Sight Flow Indicator
The Rising Ball is supplied in stainless steel or bronze to be used on pipe sizes from 8mm to 40mm (¼” to 1 ½”).
The PTFE ball rises as the flow starts becoming clearly visible.
The indicator must be installed horizontally with the glass dome positioned upwards.
Applications
- Ensuring that flow of cooling water or lubricating oil is maintained to specialised equipment
- Detecting changes in colour and condition of liquids during processing
- Showing the presence of condensate in steam return lines
- Indicating chemical dosing on water treatment plant
- Designed and manufactured in the UK
- Robust with good shock and vibration resistance
- Short lead times
- No routine maintenance required
- 8 – 25mm (1/4” to 1 ½”) connections available
- Unrivalled flow and pressure drop performance
- Bi-directional flow
- Operates over a wide flow range
